Gas Filters

DESCRIPTION

It is a device that prevents the passage of a particles of dust or debris brought by the gas, protecting the regulation and safety device. FM gas filters have a large filtering component is fully removable for complete inspection and cleaning. Special O-Ring sealings, resistant to third gas family, make easy removal. MADAS filters permits upstream pressure measurement through an appropriate standard connection.

Reference standard EN 126
In conformity with:
Direttiva PED 97/23/CE
Direttiva Gas 2009/142/CE

TECHNICAL DATA
• Use: not aggressive gases of the 3 families (dry gases) On request biogas versions available too
• Threaded connections Rp:(DN 15 ÷ DN 50) according to EN 10226
• Flanged connections PN 16: (DN 25 ÷ DN 300) according to ISO 7005
• On request ANSI 150 flanged connections
• Max. working pressure:2 bar or 6 bar (see product label)
• Environment temperature: -40 ÷ +70 °C
• Group:2
• Filtration: 50 μm - 20 μm - 10 μm

MATERIALS
• Die-cast aluminium (UNI EN 1706)
• OT-58 brass (UNI EN 12164)
• 11S aluminium (UNI 9002-5)
• galvanized and 430 F stainless steel (UNI EN 10088)
• NBR rubber (UNI 7702)
• nylon 30% glass fibre (UNI EN ISO 11667
• viledon
